Protec tv sanyo dinamik 29inch Model CG29KX2N

07.56 By Solder Pecebeq 0 komentar




 Protec tv sanyo dinamik 29inch Model CG29KX2N








 IC LC863440 5Y67 ic chroma LA76818A =

Vertikal =LA78041

Flyback = LB51B5040N/LB51B5060N




R475 1K heater...


Q443 heater..


D486 +185v..


D003,D004 +16v vcc ic sound amp.


Pin protect utama pin 27 ic LC863440 5y67 Normal terukur 4.5v.




Dikatoda D486 0v.

Dikatoda D467 10.3v.

Colector transistor Q443 4.5v.

Dikatoda D003 12v.





Mudah2'an bermanfaat.
